Zamak alloy indexed clamping lever with threaded stud
This product is not for sale! You can choose an alternative category plastic parts.
Material: Black finish steel insert, male thread
Lever body cast Zamak (zinc, aluminum, copper alloy)
Povrch: Hladký, povrch natřený epoxidovaným práškem
Barvy těla páčky: Leskle černá (RAL 9005)
Matná černá (RAL 9005)
Oranžová (RAL 2004)
Červená (RAL 3000)
Šedá metalíza (RAL 9006)
Šedá (RAL 7031)
Modrá (RAL 5015)
| Part Number | L | R | H | D | d | c | h | h1 | h2 | h3 | d1 | Q | Price for piece |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A593-43 M04x.. | 50 | 43 | 30 | 14 | 10 | 9 | 26 | 30 | 5 | 14 | M4 | 16-20-25-30 | 3,2 EUR |
| A593-43 M05x.. | 50 | 43 | 30 | 14 | 10 | 9 | 26 | 30 | 5 | 14 | M5 | 16-20-25-30-40 | 3,2 EUR |
| A593-43 M06x.. | 50 | 43 | 30 | 14 | 10 | 9 | 26 | 30 | 5 | 14 | M6 | 16-20-25-30-40-50 | 3,2 EUR |
| A593-43 M08x.. | 50 | 43 | 30 | 14 | 10 | 9 | 26 | 30 | 5 | 14 | M8 | 25-40-50 | 3,3 EUR |
| A593-65 M06x.. | 75 | 65 | 45 | 19 | 14 | 13 | 32 | 34 | 7 | 14 | M6 | 16-20-25-30-40-50 | 3,9 EUR |
| A593-65 M08x.. | 75 | 65 | 45 | 19 | 14 | 13 | 32 | 34 | 7 | 14 | M8 | 16-20-25-30-35-40-45-50-60 | 3,9 EUR |
| A593-65 M10x.. | 75 | 65 | 45 | 19 | 14 | 13 | 32 | 34 | 7 | 14 | M10 | 20-25-30-35-40-45-50-60 | 3,9 EUR |
| A593-80 M08x.. | 91 | 80 | 57 | 22 | 16 | 16 | 40 | 42 | 8 | 16 | M8 | 20-25-30-35-40-45-50-60 | 4,6 EUR |
| A593-80 M10x.. | 91 | 80 | 57 | 22 | 16 | 16 | 40 | 42 | 8 | 16 | M10 | 20-25-30-35-40-45-50-60 | 4,6 EUR |
| A593-80 M12x.. | 91 | 80 | 57 | 22 | 16 | 16 | 40 | 42 | 8 | 16 | M12 | 20-25-30-35-40-50-60 | 4,6 EUR |
| A593-94 M12x.. | 107 | 94 | 65 | 26 | 20 | 17,5 | 47 | 50 | 10,5 | 19 | M12 | 20-25-30-35-40-50-60 | 6,6 EUR |
| A593-94 M14x.. | 107 | 94 | 65 | 26 | 20 | 17,5 | 47 | 50 | 10,5 | 19 | M14 | 30-35-40-50-60 | 6,7 EUR |
| A593-94 M16x.. | 107 | 94 | 65 | 26 | 20 | 17,5 | 47 | 50 | 10,5 | 19 | M16 | 30-40-50-60 | 6,8 EUR |
| A593-108 M12x.. | 123 | 108 | 75 | 30 | 23 | 20 | 54 | 56 | 12 | 23 | M12 | 25-50 | 8,1 EUR |
| A593-108 M14x.. | 123 | 108 | 75 | 30 | 23 | 20 | 54 | 56 | 12 | 23 | M14 | 20-30-40-50-60 | 8,2 EUR |
| A593-108 M16x.. | 123 | 108 | 75 | 30 | 23 | 20 | 54 | 56 | 12 | 23 | M16 | 20-30-40-50-60 | 8,3 EUR |
| A593-108 M18x.. | 123 | 108 | 75 | 30 | 23 | 20 | 54 | 56 | 12 | 23 | M18 | 20-30-40-50-60 | 9,1 EUR |
Pozn: Cena páčky se odvíjí od délky závitu. K obj. číslu zadejte délku závitu ve dvou.. číselných kódech (např. A593-43 M04x16)
Prices are without VAT (always for one product item). If specified order number, please, it will add it to the selected type of goods. We will be glad to send you any quantity. In case of large subscriptions, please contact us.
